DECAL LOCATIONS GENERAL INFORMATION
PAINT NOTICE Use this list to order paint for refinishing: 906315 One Gal. AG Red 906324 One Qt. Light Grey 906316 6 (12 oz. Spray Cans) AG Red 906325 6 (12 oz. Spray Cans) Light Grey
Decal Locations information is provided to assist in the proper selection and application of new decals, in the event the original decals become damaged or the machine is repainted. Refer to the listing for the illustration reference number, part number, description and quantity of each decal provided in the Kit. Refer to the appropriate illustrations for replacement locations.
The Decal Set Number for the DC2340 & DC2360 is 115867. The Set includes the following:
To insure proper selection of the correct replacement decals, compare all of the various closeup location drawings to your machine, before starting to refinish the unit. Then, circle each shown decal (on or otherwise applicable to your machine) while checking off its part number in the listing. After you have verified all the decals needed for replacement, place any extra unnecessary decals aside for disposal.
Ref. No. 1. 2. 3. 4. 5. 6. 7. 8.
NEW DECAL APPLICATION Surfaces MUST be free from dirt, dust, grease and other foreign material before applying the new Decal. To apply, remove the smaller portion of the decal backing paper and apply this part of the exposed adhesive backing to the clean surface while maintaining proper position and alignment. Peel the other portion of the backing paper off slowly while applying hand pressure to smooth out the Decal surface.
9. 10. 11. 12. 13. 14. 15. 16. 17.
CAUTION
18.
ALWAYS observe Safety Rules shown on Decals. If Decals become damaged, or the unit is painted, replace the Decals. If repainting, BE SURE that ALL Decals from the Kit(s) which apply to your machine, are affixed to your unit.
907146/AP1195
19. 20. 21. 22. 23. 24. 25.
2
Part No. 060510 060511 067493 091444 093366 093367 093373 093465 093466 093643 093653 094912 094913 094951 115974 125368 125476 126451 126453 126452 126454 126456 126457 126757 078580 078581 060138 120790
Description & Quantity Decal - Jack Storage Position Decal - Jack Lifting Position Red Reflector Strip (2 Places) DANGER – Rotating Drive Line (2 Places) Decal – Manual Location WARNING – Manual WARNING – General WARNING – 1000 RPM WARNING – 540 RPM DANGER – Moving (2 Places) WARNING – Rotating Drive Line Decal – Colorbar 12″ Decal – GEHL 3-1/4″ (3 Places) Decal – Made In USA WARNING – Block (2 Places) Decal – Disc Hardware DANGER – Rotating Knives (2 Places) Decal – 2340 Decal – 2360 Decal – 2340 & BAR Decal – 2360 & BAR Decal – GE Decal – HL Decal – Stripe 3/4″ x 10′ Manual Pouch (Not in Decal Kit) Blind Rivet (4) (Not in Decal Kit) Decal – Oil Level Decal – Hitch
