SERVICE LUBRICATION Chain transmission
Gear transmission
F E G H
Outer side bearing support
I D
N
L M
Greasing and lubricant points D) Rotor spindle lubricator E) Reduction unit oil plug F) Transmission oil fill plug G) Transmission oil drain plug H) Transmission oil fill plug I) Transmission oil level plug L) Transmission oil drain plug M) Hoe blades fixing bolts N) Outer side bearing support fill and level plugs
Lubricants
1173
1273
1181
2283 - 2293
Reduction unit oil (E)
1 (0.26)
1,5 (0.39)
Transmission oil fill chain (F)
1,4 (0.36)
-
Transmission oil fill gears (H)
-
2 (0.53)
Outer side bear. support (N)
0,18 (0.047)
-
OIL QUANTITY: lt (US gal.)
• It is advisable to use SAE 85W/140 OIL or equivalent for the reduction unit (or gear box) and side transmission. • It is advisable to use GR MU EP 2 GREASE or equivalent for all greasing points.
Bolts tightening torques - settings given in Nm (lb-ft) Fine pitch screws
CLASS
M8 x 1
6.6 15 (11)
8.8 26 (19)
10.9 36 (26.5)
12.9 44 (32.5)
M10 x 1.25 M12 x 1.25
30 (22) 51 (37.5)
52 (38) 91 (67)
74 (54) 127 (94)
88 (65) 153 (113)
M14 x 1.5 M16 x 1.5
81 (60) 120 (88)
143 (105) 214 (158)
201 (148) 301 (222)
241 (178) 361 (266)
M18 x 1.5 M20 x 1.5
173 (127) 242 (178)
308 (227) 431 (318)
433 (319) 606 (447)
520 (384) 727 (536)
M22 x 1.5 M24 x 2
321 (237) 411 (303)
571 (421) 731 (539)
803 (592) 1028 (758)
964 (711) 1234 (910)
M27 x 2 M30 x 2
601 (443) 832 (614)
1070 (790) 1480 (1090)
1504 (1110) 2081 (1535)
1806 (1333) 2498 (1843)
Service Lubrication - Page 23
