MAINTENANCE The information in this section is written for operators who possess basic mechanical skills. If you need help, your dealer has trained service technicians available. For your protection, read and follow all safety information in this manual.
Before dismounting power unit or performing any service or maintenance, follow these steps: disengage power to equipment, lower the 3-point hitch and all raised components to the ground, operate valve levers to release any hydraulic pressure, set parking brake, stop engine, remove key, and unfasten seat belt. NEVER GO UNDERNEATH EQUIPMENT. Never place any part of the body underneath equipment or between moveable parts even when the engine has been turned off. Hydraulic system leak-down, hydraulic system failures, mechanical failures, or movement of control levers can cause equipment to drop or rotate unexpectedly and cause severe injury or death. • Service work does not require going underneath. • Read Operator's Manual for service instructions or have service performed by a qualified dealer. Keep all persons away from operator control area while performing adjustments, service, or maintenance.
Reverse Cutting Edge 1. Remove plow bolts (27 & 28), hardened flat washer (25), and hex nuts (24). 2. Remove cutting edge (4) from moldboard and reverse cutting edge with sharp edge down. Reinstall hardware previously removed.
CD6156-3
5 28
24
4. 5. 24. 25. 27. 28.
27
25
4 Cutting edge Moldboard 5/8 NC Hex nut 5/8" Hardened flat washer 5/8 NC x 1-1/2" Plow bolt 5/8 NC x 2" Plow bolt
Figure 8. Cutting Edge Replacement
LR1060L TINE REPLACEMENT NOTE: Tines should be replaced when they cannot be reformed to their original configuration. 1. Remove carriage bolt (22) and flange lock nut (23) from tine beam. 2. Remove old tine.
Always wear relatively tight and belted clothing to avoid getting caught in moving parts. Wear sturdy, rough-soled work shoes and protective equipment for eyes, hair, hands, hearing, and head; and respirator or filter mask where appropriate.
3. Insert new tine, hole end first, into tine beam and align holes. 4. Secure with bolt (22) and lock nut (23).
REPLACING BLADE CUTTING EDGE 2
Remove Cutting Edge 1. Remove plow bolts (27 & 28), hardened flat washers (25), and hex nuts (24). 2. Remove cutting edge (4) from moldboard (5) and replace with new cutting edge. Re-install hardware previously removed. 5WPMAN0170 (Rev. 5/16/2008)
CD6156-4
22
2. Rake tine 23 22. 3/8 NC x 1" Carriage bolt 23. 3/8 NC Flange lock nut Figure 9. Rake Tine Replacement
Maintenance 11
