BATTERY
WARNING Do not use a booster battery and jumper cables to start the engine. Fumes vented can cause explosion and fire, resulting in property damage, serious injury or death. Refer to Engine Monitoring and review your engine’s warning system self-test routine. During your preseason start-up, make sure the warning system self-tests properly. If it doesn’t, see your DEALER. Follow Engine Starting in the Engine Starting Section and start the engine. Let it idle while you: Observe running quality - if poor, refer to Trouble Check Chart or see your DEALER. Observe water pump operation. Water must flow from the water pump indicator in a steady stream. If it doesn’t, shut off the engine and investigate. Refer to Engine Overheating. Stop the engine and check the fuel system for leaks.
WARNING Failure to check for fuel leakage could allow a leak to go undetected, resulting in fire or explosion.
Each outboard needs one battery that is: • 12-volt, heavy-duty, designated "marine" • Vented/refillable or maintenance-free Rated according to the minimum requirements in Engine Specifications. Deep-cycle batteries are suitable IF they meet or exceed the minimum CCA requirements. Ask your DEALER about your outboard’s requirements before installing longer battery cables or a battery switch. Never install an after-market battery isolator. Your outboard has a built-in accessory battery charging feature. Refer to Accessory Battery Connection.
Installation Read and understand the safety information supplied with your battery BEFORE you begin installation. IMPORTANT: You must use the adapter clamps and starwashers supplied with this outboard when installing the main battery cables to the cranking battery. Any other type of installation can damage the electrical system or EMM. Make sure all components are clean and free of corrosion. Connect the RED (+) main cable to the positive (+) battery post. Connect the BLACK (-) main cable to the negative (-) battery post. If you have marine battery posts, install each main cable on the clamp adapter with a starwasher below it. Install all wires from accessories on the threaded portion of the post.
1. Main Cable 2. Starwasher 3. Accessory wires
Maintenance -
41
