REMOTE CONTROL
WARNING If you choose a non-Evinrude remote control, be sure it has a start-in-gear prevention feature. This feature can prevent injuries resulting from unexpected boat movement when the engine starts. IMPORTANT: When selecting the remote control system for your boat, specify Evinrude components. Evinrude offers remote controls, cables and wiring kits designed specifically for your Evinrude outboards. Evinrude controls deliver the cable stroke your outboard needs for positive shift and throttle control, and they incorporate such safety and convenience features as: • Start-in-gear prevention • Plug-in compatibility with Evinrude modular wiring system
Evinrude concealed side mount control 1. Handle - shift and throttle 2. Trim/tilt switch (where equipped) 3. Neutral lock tab 4. Fast idle button 5. Throttle Friction Control
Evinrude Binnacle mount control 1. Handle - shift and throttle 2. Trim/tilt switch (where equipped) 3. Fast idle button 4. Throttle friction control 5. Emergency stop clip and lanyard
Evinrude Side mount control 1. Handle - shift and throttle 2. Trim/tilt switch (where equipped) 3. Neutral lock tab 4. Fast idle lever 5. Emergency stop clip and lanyard
General Information -
17
