ENGINE SPECIFICATIONS 100, 115 Models Displacement
105.4 cu. in. (1726 cc)
Engine Type
60° V, 4 Cylinder, Two-Cycle, Direct Injection
Full Throttle Operating Range
100, 115 - 5250 to 5750 RPM
Power (1)
100 - 100 HP (74.6 kw) @ 5500 RPM 115 - 115 HP (85.8 kw) @ 5500 RPM
Idle RPM in Gear (2)
650 ± 50
Ignition Timing (2)
Not Adjustable
Emission Control System: per SAE J1930 (2)
ECM, DFI (Engine Control Module, Direct Fuel Injection)
Fuel Requirements (2)
87 Pump Posted AKI (90 RON) - Refer to Fuel and Oil
Oil
Evinrude direct injection oil - Refer to Fuel and Oil
Warning Signals
Controlled by the engine’s EMM
Battery, Minimum
500 CCA (620 MCA) 12 volt
Spark Plug (2)(3) Torque
Refer to ECI Label 15-22 ft. lbs. (20-30 N·m)
Start Assist Circuit Fuse
Evinrude P/N 514768
Fuses
Refer to Power Distribution Panel
Fuel Filter
Evinrude P/N 502906
Alternator
35-Amp, Fully Regulated
Gearcase - Lubricant Capacity
Evinrude Ultra-HPF™ gearcase lubricant L Models - 26 fl. oz. (770 ml) X Models - 42 fl. oz. (1250 ml)
Pwr. Trim/Tilt - Fluid Capacity
21 fl. oz. (622 ml)
Propeller (4)
Refer to Propeller Selection
Weight (7)
L Models - 365 lbs. (166 kg) X Models - 390 lbs. (177 kg)
Sound at Driver’s Ear (LpA) ICOMIA 39.94
80.8 dB(A)
Transom Height
L Models - 19 1/2 to 20 in. (495 to 508 mm) X Models - 24 1/2 to 25 in. (622 to 635 mm)
