X OIL AND FUEL
OIL AND FUEL OILING SYSTEM
Remove the engine cover to access the oil tank.
If the “LOW OIL” warning light illuminates, you have approximately five hours of normal operation before running out of oil when using TC-W3RL oil. If using Evinrude/Johnson XD100™ oil, you have approximately ten hours of normal operation remaining. Refill the onboard oil tank at next convenient opportunity. Refer to Priming the Oiling System on page 17. IMPORTANT: Always “top off” your oil tank prior to prolonged usage or long trips.
FILLING THE OIL TANK
Remove the filler cap and fill the tank with the Release the port and starboard engine cover recommended outboard lubricant, as specified in Oil Requirements on page 18. latches by turning each handle downward.
Pull up on the tilt handle to release the engine cover seal on the engine cover.
Replace the filler cap and tighten securely. Reinstall the engine cover. IMPORTANT: The oil tank capacity is 2.0 quarts (1.9 liters).
1
1. Tilt handle
PRIMING THE OILING SYSTEM The oiling system must be primed before reusing the outboard if: • You run completely out of oil; or • The outboard is laid down for transportation or storage. Prime the oiling system by performing winterization. Refer to Long-Term (Winterization) on page 39.
