Eaton Product Repair Manual
Page 35 of 49
__________________________________________________________________________________________________________________________________________ Subject:
72400 BACK TO BACK PISTON PUMP REPAIR MANUAL
Appendix D – Hydraulic Remote Control Basic Assembly
ITEM 61-1 61-2 61-3 61-4 61-5 61-6 61-7 61-8 61-9 61-10 61-11 61-12 61-13 61-14 61-15 61-16 61-17 61-18 61-19 61-20 61-21 61-22
QTY 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 4 2 2 2 2
DESCRIPTION HOUSING, HYDRAULIC REMOTE CONTROL SPOOL, SERVO WASHER SPRING, CYLINDRICAL COMPRESSION WASHER RING, ROUND EXT RETAINING SPOOL SUBASSY LINK, FEEDBACK PIN, DOWEL RING, EXTERNAL CLIP RETAINING PLUG SUBASSY PLUG, SPOOL O-RING SPACER SPACER GASKET COVER, END SCREW, UNC HEX SOCKET HD CAP SCREW, UNF HALF DOG POINT SET THREADSEAL WASHER, COUNTERSUNK NUT, UNF THIN FINISHED HEX
Figure 3-2
