TROUBLESHOOTING GUIDE ISSUE
CAUSE
1. Pump does not 1. Wrong Voltage start
2. Low capacity or low head
SOLUTION Check that pump is plugged into a socket with the proper voltage.
2. No Power
Check that pump is plugged into a live socket.
3. Damaged electrical cable
DO NOT use pump. Contact your dealer for further instructions.
4. Bad fuse
Replace fuse.
5. Opened thermal contactor
Check if motor is overheated. If that is the case, unlock rotor or check electrical connections.
6. Fauled impeller
Check if impeller is entangled. Make sure impeller is clean and freely rotating.
1. Impeller is not rotating smoothly
Check that the impeller runs counterclockwise when plugged into power sourse. 1. Tilt pump at slight angle on base. 2. Plug elecrical cord into power sourse briefly to check that the pump rolls to the right, or moves in a counterclockwise direction.
2. Clogged passages
1. Clean filter, impeller, pump housing, broken pipes and/or clogged hoses. 2. Check if discharge hose is too long or kinked. Change hose to proper specifications and good working condition.
17
