Instrument/controls - Description and function Control panel – Alarms (cont.) SYMBOL
DESCRIPTION Warning symbol, hydraulic oil filter.
If the symbol appears with the engine in maximum rpm, it shall be necessary to replace the hydraulic oil.
Warning symbol, air filter.
If the symbol appears with the engine in maximum rpm, it shall be necessary to clean or replace the air filter.
Warning symbol, battery charging.
If the symbol appears with the engine running, the alternator is not charging. Stop the engine and find the fault.
Warning symbol, engine temperature.
If this symbol appears, the engine is too hot. Stop immediately the engine and find the fault. Refer also to the engine manual.
Warning symbol, temperature.
26
FUNCTION
hydraulic
oil
This symbol appears when the hydraulic oil is too hot. Do not drive the roller, put the engine on idle, wait until the oil cools down and find the fault.
Warning symbol, low fuel level.
This symbol appears when the fuel level is 10%.
Warning symbol, low sprinkler water level.
This symbol appears when the sprinkler water level is 10% in the main tank.
Warning symbol, low braking capacity.
This symbol appears when the oil level and/or pressure for the brakes are low. If this alarm appears and remains with the machine working, stop it immediately and contact DYNAPAC.
