Machine description - Instruments/Controls Function descriptions No
Designation
Symbol
Function
1
Horn, switch
Press to sound the horn.
2
Starter switch
The electric circuit is broken. All instruments and electric controls are supplied with power. Starter motor activation.
3
Hazard beacon, switch (Optional)
Turn to the right to switch on the hazard beacon.
4
Working lights (Optional)
Turn to the right to switch on the working lights.
5
Emergency stop
Push in to activate the emergency stop.
7
Warning lamp, battery charging
If the lamp comes on while the engine is running, the alternator is not charging. Stop the engine and locate the fault.
8
Brake warning lamp
The lamp come on when the parking or emergency brake knob is depressed and the brakes are applied.
9
Warning lamp, engine oil pressure/temperature
This lamp lights if the engine is too hot or the oil pressure is too low. Stop the engine immediately and locate the fault. Refer also to the engine manual.
10
Warning lamp, hydraulic filter
If the lamp comes on while the diesel engine is running at full speed, the hydraulic fluid filter must be changed. Change when the oil is at normal operating temperature.
11
Warning air filter
If the lamp comes on while the engine is running at full speed, the air filter must be cleaned or replaced.
12
Temperature gauge, hydraulic fluid
Indicates the temperature of the hydraulic fluid. Normal temperature range 65°-80°C (149°-176°F). Stop the diesel engine if the lamp comes on. Locate the fault.
13
Amplitude / Frequency selector, switch
The left position gives low amplitude / high frequency. In the central position, amplitude / frequency is switched off. The right position gives high amplitude / low frequency.
14
Speed selector, drum
Transport speed (High) Working speed (Low)
30
