Maintenance – Annually 8.9.9 Checking the hydraulic oil level Protective equipment: n Working clothes n Protective gloves 1.
Park the machine in secured condition Ä Chapter 6.4 „Parking the machine in secured condition“ on page 53.
2.
Adjust the steering rod with height adjustment so that the area with the filler plug is horizontal.
3.
Unscrew the filler screw.
4.
Press the travel lever forward against the end stop and hold it in this position.
5.
The oil level must reach the mark on the steering rod head, if necessary, fill in hydraulic oil.
Fig. 91
Fig. 92
Mark: approx. 40 mm (1.6 in) below the filler opening
Fig. 93 Topping up hydraulic oil and bleeding the hydraulic system
88
NOTICE! Components may get damaged! – Use only oil of the permitted specification.
DRP25D
