OPERATION OF THE T12000 TRANSMISSION THE TRANSMISSION ASSEMBLY
MOT12000T20
OPERATION OF THE T12000 TRANSMISSION THE TRANSMISSION ASSEMBLY Basically the transmission is composed of five main assemblies: 1.
The converter, pump drive section and pressure regulating valve.
2.
The input shaft and directional clutches.
3.
The range clutches.
4.
The output section.
5.
The transmission solenoids.
