7. Maintenance
500 Hours Service Maintenance to be performed every 500 hours of operation.
1. Engine 1.1. Change oil 1*
If the dump truck is used for particulary demanding operation, especially in a dusty environment or if the deposits in the centrifugal cleaner are thicker than 20 mm: Change oil more often. 1. Remove the cap on the drain plug, install the draining hose (tool kit) and drain the oil when the engine is hot. Access through the drain hole in engine bottom guard (1).
1
2. When all oil is drained, remove the draining hose and reinstall the cap. 4. Reinstall the cover for drain hole in engine bottom guard. 5. Fill oil through filler (2). Do not overfill! 6. Check oil level on dip stick (3).
CAUTION The oil may be hot! Wear protective gloves and eye protection.
3
2
* Numbers refer to positions on the lubrication schedule, chapter 6 Operating & Maintenance Manual
153
