5. Operating Instructions
13. Manual release of parking brake If the parking brake can not be disengaged by the parking brake lever i.e. air pressure has been lost, it may be manually released: 1. Place wheel chocks under the wheels. mm 82,6
2. Raise the body and secure it with the body support (see chapter 2 - safety instructions) 3. Remove the dust plug on the air cylinder. 4. Insert and lock the release bolt into piston. • The release bolt, washer and nut are to be found under the air cylinder. 5. Tighten the nut against the washer, until the bolt extends 82,6 mm.
DANGER All braking systems are now out of function. Extreme care must be taken to avoid spontaneous rolling.
