5 - ASSEMBLY
5 - ASSEMBLY Install
Two-function joystick to two-function lever (electro-hydraulic) conversion kit 1. Inside the cab, on the right-hand side of the seat box, disconnect the wiring harness (AA) from the main cab harness (AB). 2. Remove the clamps and the bolts (AC) to unfix the wiring harness (AA). Keep for later use.
LEIL19WHL0358AA
1
LEIL16WHL0734BB
2
3. Remove the three lower armrest mounting bolts (A) and the washers (B) on the right-hand side of the armrest (C). 4. Lift the arm pad to the top of its adjustment. Reach the latch located under the arm pad and push the latch forward to release the mechanism. Turn the arm pad of 90° to access the two top mounting bolts (A) and the washer (B). 5. Remove the two top mounting bolts (A) and the washer (B). 6. Remove the right-hand armrest from the seat.
9 EN
