4 - ASSEMBLY
Lift assembly installation 29. Install the link (16) to the coupler with the existing pin and the retaining rings.
RAIL14TLB0311BA
16
RAIL14TLB0878BA
17
RAIL14TLB0879BA
18
30. Working from inside the cab, remove the plug (R) on the front left-hand instrument panel (S) . 31. Loosen and remove the fastening screws (T). 32. Paying attention to the electric connections, partially lift the front left-hand instrument panel (S) to make the lower side accessible.
33. Remove the screws fastening (U) of the side instrument (V). NOTICE: Care must be used when pulling the panel away from the cluster so that there is no damage to the wire harnesses.
12 EN
