5 - ASSEMBLY
NOTE: apply the angle orientation to the hose (18) and elbow (16) as shown in figure 5. NOTE: apply the angle orientation to the hose (17) as shown in figure 5.
LEIL19CWL0158FB
5
8. Secure the tubes (12) and (13) to the right side of front chassis by means of the two plates (9), the two clamps (8), the two washers (10), and the two bolts (11). NOTE: align the clamp side shown on the figure 6 (see arrow) to mark on tubes (12) and (13).
LEIL20CWL1046AB
6
10 EN
