3 - ASSEMBLY
25. Install the front axle suction tube (31) to the front axle return tube (34). 26. Fix, on the welded plate (S), the front axle return tube (35), the rear axle suction tube (33) and the front axle return tube (34). Secure with the clamp (38), the cover (39), the clamp (40), the flange bolt M8x50 (52) and the washer 9x16x1.6 (51). 27. Install the nut (14) and the 90° elbow (27) to the front axle return tube (35). 28. Install the nuts (24) and the 90° elbows (26) to the rear axle suction tube (33) and to the front axle return tube (34).
LEIL17WHL2263GB
8
18 EN
