3 Modules Module assignment 2484
Module A62 - External control (EXT) Module A62 - External control (EXT)
42 28 14
29 15 1
401264
Pin
Function
CCN
Component
Circuit diagra m
Measuri ng variable
Directio n
1
Power supply for power
F09
Fuse
8a, 8b, 9a, 10a
12 Volt
Input
2
ISO transmission pulses (theor. ground speed)
LX2
Snap-on connection
11a
Frequen cy
Output
3
Power relay for ISO sockets
K3, K4
Relay
10a
12V
Output
4
Hydraulic valve 1 (white) lower, with external control
XCD
Snap-on connection
9a
Ground
Input
5
Hydraulic valve 2 (red) lower, with external control
XCD
Snap-on connection
9a
Ground
Input
6
Lighting (parking light)
F76
Fuse
9a
12V
Input
7
not used
-
-
9a
-
Input
8
not used
-
-
8a, 8b
-
Input
9
Hydraulic valve 2 (red) raise, with external control
XCD
Snap-on connection
9a
Ground
Input
10
Hydraulic valve 3 (yellow) raise, with external control
XCD
Snap-on connection
9a
Ground
Input
11
Hydraulic valve 4 (green) raise, with external control
XCD
Snap-on connection
9a
Ground
Input
12
not used
-
-
9a
-
-
13
Vehicle CAN1 Low
-
-
6a, 6b
3.2±0.2
-
Volt eff 14
Power supply (electronics) of EXT module
F10
Fuse
6a, 6b
12V
Input
15
not used
-
-
-
-
Output
84
000 293 647 2 - SYS-E XERION 3300 - 02/06
