3 Modules Module assignment 2484
Cab fan speed controller module A7
8 4
5 1
401271
Pin
Function
CCN
Component
Circuit diagra m
Measuri ng variable
Directio n
6
not used
-
-
-
-
-
7
Fan
A6
Automatic air conditioner module A6
38b
12V PWM
Input
8
Power +
F54
Fuse
38b
12V
Input
Module A15 - Electronic engine control CAT Module A15 - Electronic engine control CAT
401261
Pin
Function
CCN
Component
Circuit diagra m
Measuri ng variable
Directio n
4
Power supply sensor
B153
Ground drive pedal sensor
41
12V
Output
5
PWM reference
-
-
2, 41
0V
Input
8
Diagnosis
XM
CAT engine diagnosis plug
2
---
---
9
Diagnosis
XM
CAT engine diagnosis plug
2
---
---
28
Error code (flashing code)
D02
Diagnosis LED
2
---
Output
40
