1 Introduction Structure of electrical documentation 2482
– – – – – –
ye= yellow gn =green gr = grey pi = pink or =orange vi = violet
– – – – – – – – – – – – – – – – – – –
A = Terminal / Module B = Sensor C = Device E = Lighting F = Fuse G = Voltage source H = Signalling unit / signal light K = Relay M = Electric motor P = Indicator R = Potentiometer / resistor S = Switch - Cab operation T = Switch - Terminal operation U = Switch - External operation V = Electronic component W = Antenna X X = Connector Y = Solenoid coil Z = Actual value function switch
CLAAS standard:
000 293 647 2 - SYS-E XERION 3300 - 02/06
