03 CHASSIS - NEXOS 2 WHEEL DRIVE disassembly and assembly operations
Assembly – If previously removed, assemble two new bushes (4) and (8) into the axle beam (5) using the prescribed special tool.
Fig. 60
– If previously removed, assemble two new bushes (1) and (2) into the knee (3) and two new bushes (12) and (13) into the knee (11).
Fig. 61
– Insert the two knees (3) and (11) into the axle housing (5). – Regolate the outside lenght of both knees.
Fig. 62
46
Nexos Elios 240-210 – EN
