USING FLEXPILOT
ON / OFF : Activating FLEXPILOT Control: Isolation valve ( A). Vertical = ON Horizontal = OFF 1st function : Lifting / Lowering the loader
A
Control — Forward
= Lowers the loader, first step S.A, then D.A
— Backward
= Raises the loader.
17
2nd function : Implement Crowding / Dumping FRONT
LEFT
Control — To the left
= Implement crowd.
— To the right
= Implement dump.
RIGHT
REAR
3rd function Control Press GREEN button while moving lever right or left 4th function / SCS Control Press BLUE button while moving lever right or left ACS : Retun to dig Press BLACK button, implement will crowd.
19
FAST-LOCK / SPEED-LINK : Automatic implement locking unlocking GREEN
ORANGE Control Press ORANGE and GREEN buttons while moving lever :
BLACK
— To the left
= Locking.
— To the right
= Unlocking.
BLUE
20
11
00 1142 032 0
