Measurement and control Checking the oil pressure Test conditions : – Engine running idle, empty. – Oil temperature at 93°C.
HYDRO TESTER
101msm63
Fig. 42
– Connect a hydraulic fitting to the pressure tap (1/8 - 16 x 200). – Connect test set n° 00 0178 310 0. The measured pressure must be 1,05 bar.
Arion 630-610 C – 09.2008 – GB
A1.47
