Operation Checklist “Putting the machine into service” After starting the engine and during operation, check and observe the following points: Checklist “Putting the machine into service”
See page
1 Indicator lights for engine oil pressure and alternator gone out?
3-31
2 Braking effect sufficient?
3-44
3 Temperature gauge for engine coolant in normal range?
3-6
4 Steering system working properly?
3-40
5 Anyone dangerously close to the machine?
–
6 Safe load indicator checked and OK?
3-56
7 3rd control circuit locked and secured?
3-60
When driving on public roads, particular attention should be paid to the following points: 8 Telescopic boom completely retracted?
3-61
9 Bucket and attachments in transport position? 10 Transport guards (front-edge protection) put in place? 11 Control lever for lift and tilt hydraulics of the telescopic boom locked?
– 3-60
“Parking” checklist Check and observe the following points when parking the machine: Parking checklist
See page
1 Attachments on the telescopic boom lowered to the ground?
3-61
2 Parking brake applied?
3-45
3 Diesel engine stopped?
3-31
4 Cab locked, especially if the machine cannot be supervised?
–
When parking on public roads: 5 Machine adequately secured?
–
When parking on slopes: 6 Machine additionally secured with chocks under the wheels to prevent it from rolling away?
3-12
–
