Operation 3.10 Drive interlock with transponder key (option) The drive interlock is a self-activated security system. 30 seconds after switching off ignition (“zero” position or ignition key removed), the drive interlock is automatically activated (locked), which is indicated by a flashing red light. Scope of delivery: • Drive interlock installed in the machine • Transponder key A (coded) • Master key (main key)
Important! Store the master key in a safe place, separately from the transponder key • It is used to code (“train”) a new transponder key
Disabling (releasing the drive interlock)
☞ Hold transponder key A about 2 cm over mark 74 ➥ The red telltale B goes out and the ➥ drive interlock is released for 30 seconds (disabled) 00000
00
B
h
74
☞ Switch on the ignition lock and start the engine ➥ – see Starting the engine on page 3-16 ➥ The drive interlock is disabled as long as the engine runs
A
Fig. 39: Drive interlock (option)
Enabling (locking the drive interlock)
☞ Switch off the engine ☞ Apply the parking brake – see Parking brake on page 3-25 ☞ Remove the ignition key! ➥ The drive interlock is enabled in 30 seconds ➥ The red telltale B flashes
000 293 934 2 – BA SCORPION
3-17
