Prior to operation ADJUSTMENTS TO THE FORAGER The maize header is designed for operation with the forager Type 493. The following adjustments must be made to the forager before attaching the maize header.
Additional weights Forage harvesters with a front attachment installed must be equipped with additional weights according to the traffic regulations of your country for transport on public roads and ways. This is necessary so that the machine's drive axle is not overloaded and the machine does not lift at the rear on braking and when travelling on slopes. The load on the steering axle wheels should be 20% of the machine weight with mounted maize header. Attaching the additional weights – see forage harvester operator's manual. Required additional weights Forager model:
Number
JAGUAR model 493 with standard steering axle:
14
JAGUAR model 493 with powwred steering axle:
13
Order numbers – additional weights Quantity Description
Weight
Order No.
13 additional weights
1443 kg
S09 0085
14 additional weights
1554 kg
S09 0087
Additional lighting for road transport
A
The normal front driving lights of the forage harvester are covered by the maize header when it is in transport position.
A
Mount additional lighting (A) – see fitting instructions for accessory set. Headlights on top and turn flashers on the sides Order number: 6
7.3
S03 0020
(Fig. 6)
ABA/BA RU 600 Contour / Auto-Contour - 0293 623.0
