Assembly
22
23
24
21
14
25
20
19
14 21
19
17
26
27 66252_01
4 Attach the tension rope (20) with an S-hook (24) at the rear to the tailgate in the slotted holes of the metal track (23). Guide it through the eyelets (19) to the hoops. Attach the other S-hooks to the tailgate again in the slotted holes of the metal strip (23). Slide the rod (25) through the S-hooks to lock it. Double the side tension rope (21) over and fix it to the rear bracket (22). Attach it to the front bracket with the S-hook (27) in the eyelets (26). (Fig. 3, 4)
7.4
BA QUANTUM 6800 P / 6500 P / 5500 P-18 / 5500 P-16 / 5500 GT / 5500 P / 4500 P - 0299 613.7
