3 Working hydraulics Corn cracker 3254
Key to diagram Item
Designation
Remark
A
Figure
Cracker adjusting range (26 mm piston stroke)
B
Figure
Venting range (piston on double pump overall length 231 mm)
a
Port
to left adjusting cylinder
b
Port
to right adjusting cylinder
c
Port
Filling port
d
Piston
is turned in or out for cracker gap adjustment
e
Port
for venting the cracker gap adjustment
-
-
-
230
Corn cracker adjustment pump
Serves as a proportioning pump for cracker adjusting cylinder
-
-
-
356 R
Cylinder
Cracker gap adjustment, right
356 L
Cylinder
Cracker gap adjustment, left
Adjusting and venting Adjusting the minimum Corn cracker gap
Adjust minimum corn cracker gap at the corn cracker adjustment (double pump 230). Check the gap dimension between the corn cracker rollers at the largest diameter (when rollers are worn), set value = 0.5 mm. Adjustments are carried out on the stop bolts (S).
230 C e
401125
000 293 892 1 - SYS-H JAGUAR 493 - 03/06
S
356L
73
