2 Steering hydraulics Testing and measurements 3253
Description of function Steering hydraulics measuring point
909 Steering hydraulics measuring point
Measuring pre-conditions:
Pressure measurements are carried out at: – maximum volume flow (maximum motor speed), – an oil temperature of 45 – 50 °C
Pressure measurement:
Circulation pressure = 17+8 bar System pressure = 150+15 bar Shock valve = 200±15 bar
000 293 892 1 - SYS-H JAGUAR 493 - 03/06
45
