1 Overall hydraulic system Tier 3 diesel engine / with cooling circuit pump (246) 3252
Item
Designation
Remark
323
Steering hydraulics cylinder
-
332
Pick-up crop guard lift hydraulic cylinder
-
333
Pick-up auger lift hydraulic cylinder
-
340
Cover hydraulic cylinder
-
341
Sharpening stone movement hydraulic cylinder
-
351
Front attachment raise/lower hydraulic cylinder
-
352
Front attachment clutch hydraulic cylinder
-
353
Front attachment reverse hydraulic cylinder
-
355
Ground drive servo control motor hydraulic cylinder
-
359
Shifter rail locking hydraulic cylinder
-
-
-
-
405
Orifice plate Ø 0.6 mm
-
406
Orifice plate Ø 0.8 mm
-
408
Orifice plate Ø 1.2 mm
-
412
Orifice plate Ø 2.0 mm
-
413
Orifice plate Ø 2.2 mm
-
421
Restrictor A
(option for maize headers)
441
Rotary coupling
-
-
-
-
501
Working hydraulics pre-pressurization accumulator
120 bar
511
Front attachment relief accumulator
40 bar
520
Feed pressure accumulator
10 bar
521
Quick stop accumulator
60 bar
-
-
-
609
Orbitrol steering unit rotary disc valve
-
612
Front attachment load switch-over valve
-
614
Front attachment lower flow control valve
-
617
Working hydraulics pre-pressurization relief screw valve
-
703
Working hydraulics pressure relief valve
180+10 bar
706
Pressure relief valve
3 bar
707
Pressure holding valve (non-return valve)
-
713
Ground drive multifunction valve backward valve
420 bar DP
714
Ground drive multifunction valve forward valve
420 bar DP
716
Ground drive feed pressure relief valve
24 bar
719
Ground drive tap pressure control valve
-
721
Ground drive oil tapping shuttle valve
-
000 293 892 1 - SYS-H JAGUAR 493 - 03/06
19
