6 Ground drive hydraulics High-pressure sensor (B97, B98)Control 3258
High-pressure sensor (B97, B98) Fig.
102
B98
Designations Item
Designation
Remark
B98
Drive hydraulics backward high-pressure sensor
The drive hydraulics forward high-pressure sensor (B97) is installed on the opposite side.
102
Pressure filter
-
Description of function The ground drive hydraulics forward (B97) and backward (B98) highpressure sensors are installed in the pressure outlets of the ground drive variable displacement pump (211).The ground drive hydraulics forward highpressure sensor B97 permanently transmits the ground drive pressure to the ground drive module (A49). This signal controls the motor rpm and the swivel angle of the ground drive variable displacement motor (210).The ground drive hydraulics backward high-pressure sensor B98 permanently transmits the ground drive pressure to the ground drive module (A49). This signal controls the motor rpm and the swivel angle of the ground drive variable displacement motor (210).
178
000 293 892 1 - SYS-H JAGUAR 493 - 03/06
