1 Overall hydraulic system Tier 2 diesel engine / without cooling circuit pump 3250
Item
Designation
Remark
332
Pick-up crop guard lift hydraulic cylinder
-
333
Pick-up auger lift hydraulic cylinder
-
340
Cover hydraulic cylinder
-
341
Sharpening stone movement hydraulic cylinder
-
351
Front attachment raise/lower hydraulic cylinder
-
352
Front attachment clutch hydraulic cylinder
-
353
Front attachment reverse hydraulic cylinder
-
355
Ground drive servo control motor hydraulic cylinder
-
359
Shifter rail locking hydraulic cylinder
-
-
-
-
405
Orifice plate Ø 0.6 mm
-
406
Orifice plate Ø 0.8 mm
-
408
Orifice plate Ø 1.2 mm
-
412
Orifice plate Ø 2.0 mm
-
413
Orifice plate Ø 2.2 mm
-
441
Rotary coupling
-
442
Venturi meter
-
-
-
-
501
Working hydraulics pre-pressurization accumulator
120 bar
511
Front attachment relief accumulator
40 bar
520
Feed pressure accumulator
10 bar
521
Quick stop accumulator
60 bar
-
-
-
609
Orbitrol steering unit rotary disc valve
-
612
Front attachment load switch-over valve
-
614
Front attachment lower flow control valve
-
617
Working hydraulics pre-pressurization relief screw valve
-
703
Working hydraulics pressure relief valve
180+10 bar
706
Pressure relief valve
3 bar
707
Pressure holding valve (non-return valve)
-
713
Ground drive multifunction valve backward valve
Δp=420 bar
714
Ground drive multifunction valve forward valve
Δp=420 bar
716
Ground drive feed pressure relief valve
24 bar
719
Ground drive tap pressure control valve
-
721
Ground drive oil tapping shuttle valve
-
725
Steering double shock valve
200 bar
000 293 892 1 - SYS-H JAGUAR 493 - 03/06
11
