Assembly ASSEMBLING THE MOWER UNIT Use as a front-rear combination NOTE! The DISCO 8550 AS Plus (with swath displacers) can only be operated as a front-rear combination! (Fig. 4)
4
64532F
DANGER! Work on the mower unit may only be carried out with the drive disengaged and the engine switched off. – Remove the ignition key! Only work on a raised mower unit when it is securely supported. – Use suitable stands!
Safety frame side mower units Fit the safety frame in accordance with Fig. 7 and attach it to the conditioner framework.
4 2
Place the safety guards (1) over the safety frames (2) of the side mower units and secure with the belts (4).
4
(Fig. 5, 6) 1 67214
5
NOTE! For easier attachment of the belts, the lower screws (3) can be removed and the safety frame swung upwards out of the way.
4
(Fig. 7) 4 6
00 0293 732 4 - ZBA / BA DISCO 8550 AS Plus
6.2
