General description Description 1 Selection proportional to engine speed or forward driving lever “Z162”. 2 Lever for selecting the 540 "Z161" or 1 000 "Z160" rev/min speed. 3 Economical load selection lever "Z159". A30 "Cebis MFT" terminal module. A57-3 "TR3" transmission module. A101 Dashboard and "DBD" CAN network communication module. B142 PTO speed sensor. S173 Rear PTO brake control. S172 Rear PTO automation activation control. S114 PTO engaging control. U50-1 PTO engaging left external button. U50-2 Right external PTO engaging button. U53-1 Left emergency stop external button. U53-2 Right emergency stop external button. Y325 Rear power take-off clutch solenoid valve. Y338 Rear power take-off brake solenoid valve.
Component layout
A
B
C
Fig. 3
394msm80
Description A Rear power take-off clutch.
C Interchangeable power take-off sleeve.
B Transmission shaft.
Arion 640-510 – 09.2008 – GB
C2.5
