Hydraulics 98 l/min Localization on right hydraulic cover
9055a
7006a
Y338
Y182
Y325 Y105
Y1 Z183
9055b 9010
6042
1013
M
5016
7006b 1027 394msm0w
Fig. 24
Description 1013 Suction strainer, 150 µ.
Y1 4-wheel drive solenoid valve.
1027 15 micron high pressure filter.
Y105 Differential lock solenoid valve.
5016 Operating brake accumulator.
Y182 Solenoid valve for coupling the hydraulic pumps.
6042 Brake valve.
Y325 Rear power take-off solenoid.
7006a 195 bar pressure restricter of the 19 cm3 pump.
Y338 Power take off brake solenoid valve.
7006b 195 bar pressure restricter of the 14 cm3 pump.
Z183 Suction circuit pressure switch.
9010 Piloting pressure tap.
M Supply to trailer hydraulic brake coupling "8036".
9055a High pressure connector (14 cm³ pump). 9055b High pressure connector (19 cm3 pump or 14 cm3 and 19 cm3 coupled pumps).
