Hydraulics 60 l/min "7029" 20-bar valve on 60 l/min low pressure circuit Description
Z184
1 Spool. 2 Spring. 3 Orbitrol supply. 4 To solenoid valves. 5 To oil cooler. Z184 Transmission control circuit pressure switch.
4
The drawer (1) is balanced between the force exerted by the spring (2) and the pressure in the duct linking the solenoid valves (4) to maintain 20 bar.
3 1 2
5
394msm32
E1.24
Arion 630-610 C – 10.2008 – GB
Fig. 15
