Engine Engine module The “ENG” engine module is new compared with the “Powertech Plus” engine module, as it has only 2 connectors.
101msf02
Fig. 3
101hsm26
Fig. 4
Identification The identification plate is located on the right side of the engine, behind the exhaust pipe Engine serial number (E.g. : 6068L000065) CD : Manufacturing site 6 : 6-cylinder engine 068 : Displacement 6,8 litres L : (Can also be M, N, P) : TIER III 000065 : Engine number in the series Engine type (E.g. : 6068HRT82) 6 : 6-cylinder engine 068 : Displacement 6,8 litres H : Type of induction (turbocharger with intercooler) RT : CLAAS Tractors application 82 : Application number
Arion 630-610 C – 09.2008 – GB
A1.3
