Engine Description C E
Y320
D
A15
B
101msm58
Fig. 1
101msm59
Fig. 2
Description A15 “ENG” engine module.
D Heating flange.
B Injection system “common rail”.
E Identification plate.
C Turbocharger.
Y320 Injector.
– “Powertech E” engines are fitted with a common rail injection system similar to that on the “Powertech Plus”, except that the injectors are fitted outside the cylinder
A1.2
head cover. This faily of engines features a fixed geometry turbocharger, an internal exhaust gas recycling system and 2 valves per cylinder.
Arion 630-610 C – 09.2008 – GB
