Operation 3.10 Air-suspension seat (option) Important notice on air-suspension seat operation Before putting the machine into operation, check the switches on the seat for correct function.
Danger! In order to avoid danger of accidents, do not put a machine into operation with a defective air-suspension seat!
☞ Have the seat repaired by an authorised workshop
Air-suspension seat operation The air-suspension seat height can be adjusted continuously. There are two settings for the automatic weight adjustment. The second setting allows for an individual height adjustment. ☞ Pull or press lever 4
➥ Seat height changes ➥ Upon reaching the upper or lower limit, the height is automatically adjusted to
4
ensure a minimum spring travel
Caution! Do not run the air compressor for more than 1 minute to avoid damage to it!
Fig. 66: Air-suspension seat
3.11 Fire extinguisher (option) Fire extinguisher operation The fire extinguisher is not included in the machine's standard equipment (option). If a fire extinguisher is retrofitted according to DIN-EN 3, then this must be carried out by an authorised workshop ☞ Operate the fire extinguisher according to the instructions printed on the fire extinguisher.
Caution! In order to ensure the full serviceability of the fire extinguisher, ☞ Have the fire extinguisher checked at regular intervals and refilled • See the inspection tag ☞ Remove the fire extinguisher from the cab in an emergency only ☞ After the fire extinguisher has been used: have it filled by an authorised workshop, or replace it with a new one
Fig. 67: Fire extinguisher (option)
l
00 0291 909 0 – BA SCORPION
3-21
