Operation Drive interlock (option)
The drive interlock is a self-activated security system. 30 seconds after switching off ignition (“zero” position or ignition key removed), the drive interlock is automatically activated (locked), which is indicated by a flashing red light. Scope of delivery: • Drive interlock installed in the machine • Transponder key A (coded) • Master key (main key)
Important! Store the master key in a safe place, separately from the transponder key • It is used to code (“train”) a new transponder key Disabling (releasing the drive interlock)
00000
00
C
h
B Fig. 37: Drive interlock (option)
000 294 145 0 – BA SCORPION
☞ Hold transponder key A about 2 cm over mark B ➥ The red telltale C goes out and the ➥ drive interlock is released for 30 seconds (disabled) ☞ Switch on the ignition lock and start the engine ➥ – see Starting the engine on page 3-16 ➥ The drive interlock is disabled as long as the engine runs Enabling (locking the drive interlock)
A
☞ Switch off the engine ☞ Apply the parking brake – see Parking brake on page 3-24 ☞ Remove the ignition key! ➥ The drive interlock is enabled in 30 seconds ➥ The red telltale B flashes
3-17
