03 CHASSIS - ELIOS 4 WHEEL DRIVE Disassembly and Assembly
– Unscrew and remove both fastening screws (1) of the planetary carrier (3) with a wrench.
Fig. 14
– Remove the planetary carrier (3) from the wheel hub and collect the relative O-Ring (4). – Position the planetary carrier (3) on a workbench and check its wear conditions.
Fig. 15
– If required replace the planetary gears as follows: • remove the lock rings (9) on every pin; • remove the triangular plate (8); • remove the planetary gears (7) from the pins; • collect the needle bearings (6), checking their conditions; • collect the washer (5).
Fig. 16
