03 CHASSIS - ELIOS 4 WHEEL DRIVE GENERAL SPECIFICATIONS
Limited slip differential disks specifications
New separator plate thickness= 1.5±0.03 mm
New friction plate thickness= 2.8±0.03 mm
Plate ref. CA110643 - q.ty 10
Worn plate minimum thickness= 2.7 mm Plate ref. CA110642 - q.ty 2
New friction plate thickness= 1.6±0.03 mm Worn plate minimum thickness= 1.4 mm Plate ref. CA110644 - q.ty 8
Fig. 2
26
Nexos Elios 240-210 – EN
