Ground Engaging Tools – Compactor Plates/ Tips Compactor Sole Plates SERIAL NUMBER
MODEL
BLADE MODEL
SOLE PLATE
BOLTS PER PLATE
NUTS PER PLATE
814
23K,56D
Straight
4T-3019 (2)
5J-4773 (5)
2J-3506 (5)
814
36S,3YP
Straight
4T-3018 (2)
5J-4773 (4)
2J-3506 (4)
824
2HP
Cushion
4T-8799 (3)
5J-4772 (5)
2J-3505 (5)
824
35G1-222
Straight
7T-3491 (3)
5J-4773 (7)
2J-3506 (7)
824
35G223-Up
Straight
7T-3492 (3)
5J-4773 (7)
2J-3506 (7)
834
14B
Universal
4T-8799 (2)
6F-0196 (7)
2J-3505 (7)
834
36G,96G
Straight
4T-6650 (2)
5J-4772 (8)
2J-3505 (8)
834
36G,96G
Straight
4T-6651 (1)
5J-4772 (9)
2J-3505 (9)
834
64G
Cushion
4T-6645 (2)
5J-4772 (6)
2J-3505 (6)
Landfill Compactor Tip/Blades Landfill Compactor Traction Tips: ● Forged for maximum strength and equipped with ARM for critical wear areas. ● For use in applications where maximum traction is required, such as frozen or difficult to penetrate materials. Landfill Compactor Weld-On Plus Tips: ● Provide superior compaction densities, excellent traction, and excellent side hill stability. ● Provides less plugging and lower replacement costs because fewer teeth are required in its widely spaced distribution pattern. ● Lasts longer than chopper blades in high wear conditions. ARM Chopper Blades: ● Provides good traction and aggressive chopping action in all types of trash. ● Manufactured from heat-treated, DH-2 steel. ● For use in sanitary landfill applications. TRACTION TIP (lh)
(rh)
WELD-ON PLUS TIPS
ARM CHOPPER BLADE
816B,816C
107-3487 (20)
107-3488 (40)
232-0160 (20)
6Y-6766 (20)
2V-6400 (10)
2V-6401 (10)
816B,816C
107-3487 (20)
107-3488 (40)
232-0160 (20)
6Y-6766 (20)
2V-6400 (10)
2V-6401 (10)
MODEL
82
WHEEL DIAMETER (in)
ARM CHOPPER BLADE SUPPORT
826B,826C
40
107-3487 (20)
107-3488 (44)
232-0160 (25)
6Y-4321 (24)
2V-6400 (12)
2V-6401 (12)
826B,826C
48
107-3487 (20)
107-3488 (45)
232-0160 (25)
6Y-4321 (24)
2V-6400 (12)
2V-6401 (12)
826B,826C
40
107-3487 (44)
107-3488 (44)
232-0160 (25)
6Y-4321 (24)
2V-6400 (12)
2V-6401 (12)
826B,826C
48
107-3487 (45)
107-3488 (45)
232-0160 (25)
6Y-4321 (24)
2V-6400 (12)
2V-6401 (12)
836
232-0160 (35)
107-3374 (28)
2V-6400 (14)
2V-6401 (14)
836G
232-0160 (35)
107-3374 (28)
2V-6400 (14)
2V-6401 (14)
