Seals / Backup Rings Backup Rings
DIM "D"
DIM "B"
INSIDE DIAMETER
DASH SIZE
-011
DIMENSION “B” RADIAL HEIGHT RING INSIDE (MM) DIAMETER (MM)
-023
PART NUMBER
MATERIAL TYPE PTFE 55 (Duro Hardness)
1.00
11.00
0.60
115-6880
1.10
7.30
0.70
115-9530
Plastic
1.22
6.60
1.30
147-6604
PTFE 65 (Duro Hardness)
8.20
1.30
147-6605
PTFE 65 (Duro Hardness)
196.83
3.02
126-4040
PTFE 65 (Duro Hardness)
241.30
3.02
126-4004
PTFE 65 (Duro Hardness)
1.26
12.57
1.55
156-2850
PTFE 60 (Duro Hardness)
1.27
32.20
1.24
085-7530
PTFE 55 (Duro Hardness)
1.35
5.94
1.23
126-5984
Plastic
6.30
1.42
4T-5070
PTFE 65 (Duro Hardness)
6.75
1.23
126-5985
Plastic
7.90
1.42
4T-5071
PTFE 65 (Duro Hardness)
8.31
1.19
187-3513
Nitrile Rubber 90 (Duro Hardness)
1.35 1.35
-022
DIMENSION “D” AXIAL WIDTH (MM)
8.31
1.23
3E-6017
PTFE 65 (Duro Hardness)
9.72
1.23
6E-0381
PTFE 55 (Duro Hardness)
9.90
1.23
030-0167
PTFE 65 (Duro Hardness)
9.91
1.23
109-6925
Plastic
11.56
0.74
179-7257
PTFE 65 (Duro Hardness)
13.16
0.74
161-6161
PTFE 65 (Duro Hardness)
13.16
1.22
100-7000
PTFE 55 (Duro Hardness)
13.16
1.22
6V-6923
PTFE 55 (Duro Hardness)
13.16
1.23
109-6926
Plastic
14.73
0.74
169-1616
PTFE 65 (Duro Hardness)
14.73
1.22
6V-6924
PTFE 55 (Duro Hardness)
16.33
0.74
169-1617
PTFE 65 (Duro Hardness)
16.33
0.74
161-6160
Plastic
16.33
1.23
109-6927
Plastic
21.08
1.23
4T-4953
Plastic
22.68
1.25
9T-1243
PTFE 55 (Duro Hardness)
24.38
1.23
9T-4518
PTFE 65 (Duro Hardness)
1.35
25.68
1.19
115-9864
Nitrile Rubber 90 (Duro Hardness)
1.35
27.43
1.19
115-9865
Nitrile Rubber 90 (Duro Hardness)
1.40
9.20
0.50
117-0355
PTFE 55 (Duro Hardness)
11.10
0.71
187-0541
PTFE 65 (Duro Hardness)
11.20
0.50
117-0357
PTFE 55 (Duro Hardness)
12.74
0.69
185-2327
PTFE 65 (Duro Hardness)
