Preventative Maintenance – Filters Cat Fuel Water Separators ●
●
●
Removes more than 98 % of debris 10 microns and larger - and eliminates virtually all free water and more than 87% emulsified water. Minimize the risk of plunger-to-barrel scuffing and seizure in fuel injectors, reducing failure rates. Extends the life of engine fuel injectors and the secondary, high efficiency fuel filter.
Features
Benefits
Results
Thicker gauge canister
Resist canister cracking and failure in extensive field testing
Longer life and increased protection
Primary fuel filter
Removes more than 98% of debris 10 microns and larger
Minimize the risk of plunger-to-barrel scuffing and seizure in fuel injectors, reducing failure rates
Water separator
Removes virtually all free water and more than 87% of emulsified water from diesel fuel
Extend the life of engine fuel injectors and the secondary, high efficiency fuel filter
Manual screw knob
Drains the collection bowl in less than a minute
Reduces maintainance and downtime
Reusable water collection bowl
Transparent for easy monitoring
Reduces maintenance costs
Part Number
Seal Type
Application
Dimensions (mm)
Notes*
1R-0769
Axial
1R-0781
Axial
C12 & smaller
108 X 263
For engines with space constraints
C15-3412
108 X 310
1R-0770
Radial
Replaces 129-0373 & 133-5673
C12 & smaller
108 X 263
For new machines & engines
1R-0771 173-7126
Radial
C15-3412
108 X 310
For new machines & engines
N/A
Water collection bowl
N/A
This bowl fits all of the AFSI FWS part numbers
220-8678
N/A
Bowl/Can Seal
N/A
Replaceable seal for Bowl/Can interface
*For applications requiring the use of a metal bowl as a safety requirement, use 133-5673 with the 170-0062 metal bowl.
Fuel Water Separator Retrofits ENGINE Small Engines C12 & smaller Medium Engines C15-C16 3408-3412
Large Engines 3500 series
276
PRIME TIME FULL FLOW CONFIGURATION
PRIME TIME PRIME ONLY CONFIGURATION
Kit 206-5756
N/A
Base 195-1068 with 1R-0769 (axial seal) FWS or Base 177-9778 with 1R-0770 (radial seal) FWS
Kit 206-5756 The 1R-0770, included in the kit, can be replaced with the 1R-0771 for additional capacity.
N/A
Base 195-1068 with 1R-0781(axial seal) FWS or Base 177-9778 with 1R-0771 (radial seal) FWS
N/A
Kit 206-5756
(2) 207-2422 groups, each includes a 200-4139 (axial seal) FWS
BASIC CONFIGURATION
