Hose and Couplings – Bulk Hoses One-Wire Braid Hose – Fabric Covered (556) ●
PART NUMBER
HOSE I.D. (in) (mm)
HOSE DASH SIZE
Exceeds the requirements of SAE 100R5. Note: Sold by the inch.
HOSE O.D. (in) (mm)
MIN. BURST PRESS. (psi) (kPa) 82738
MAX. WORK. PRESS. (psi) (kPa)
MIN. BEND RADIUS 1 (in) (mm)
3000
3.00
9X-2362
0.188
4.8
-4
0.52
13.2
12,000
20685
76
9X-2363
0.250
6.4
-5
0.58
14.7
12,000
82738
3000
20685
3.39
86
9X-2364
0.313
7.9
-6
0.68
17.3
9000
62053
2250
15514
4.00
102
9X-2365
0.406
10.3
-8
0.77
19.6
8000
55159
2000
13790
4.61
117
9X-2366
0.500
12.7
-10
0.92
23.4
7000
48264
1750
12066
5.50
140
9X-2367
0.625
15.9
-12
1.08
27.4
6000
41369
1500
10343
6.50
165
9X-2368
0.875
22.2
-16
1.23
31.2
3200
22064
800
5516
7.36
187
9X-2369
1.125
28.6
-20
1.50
38.1
2500
17237
625
4310
9.00
229
9X-2370
1.375
34.9
-24
1.75
44.5
2000
13790
5000
3448
10.50
267
Construction: Synthetic rubber tube, textile inner braid, high tensile steel wire braid reinforcement, textile braid cover. Application: Medium pressure service with petroleum base hydraulic fluids, water-glycol and water-oil fire resistant hydraulic fluids, water, crude and fuel oils, not oil, diesel fuels, anti-freeze solutions, air. D.O.T. FMVSS 106 All Air Brake Approved. Temperature Range: -40° F to +158° F (-40° C to +70° C) for air and anti-freeze solutions. -40° F to +185° F (-40° C to +85° C) for water glycol and water-oil fire resistant hydraulic fluids, water, crude and fuel oils, hot oil, and diesel fuels. -20° F to +250° F (-29° C to +120° C) for all other applications. Usage at temperatures exceeding +200° F (+120° C) is based on reduced working pressure. Couplings: Screw-type reusable, non-skive type, see Reusable Couplings (556, 1130) section. For related assembly equipment and tooling, see Tooling section. Note: Hose cover does not need to be removed before attaching couplings. 1 Centerline of Hose
