Quick fastening
1. 2. 3. 4. 5.
Fasten the battery according to the picture. Make sure the battery lock (1) is in the down position at the bottom of the fastening slots (2). Also make sure that the locking trigger (3) is in the locking position. Release the battery according to the picture. Pull the locking trigger (3), lift up the battery lock (1) and remove the battery. Battery change rollers are positioned under the battery.
Optional battery change device is recommended for removing the battery.
