Flashing red, yellow, and green indicates a fault in the system and charging is stopped automatically.
The charger stops automatically after the charging is complete. When the charging is finished, you can unplug the charger plug and connect it to the safety socket of the truck. If the plug is not connected to the safety socket, all electrical functions will remain switched off and the truck cannot be used.
Fastening batteries Fixed fastening
1. 2. 3.
Fasten the battery according to the picture. Make sure the both battery locks (1) are in the down position at the bottom of the fastening slots (2). Also make sure that the locks are tightened.
Quick fastening
1. 2. 3. 4. 5.
Fasten the battery according to the picture. Make sure the battery lock (1) is in the down position at the bottom of the fastening slots (2). Also make sure that the locking trigger (3) is in the locking position. Release the battery according to the picture. Pull the locking trigger (3), lift up the battery lock (1) and remove the battery. Battery change rollers are positioned under the battery.
Optional battery change device is recommended for removing the battery.
